Disintegrators can be used in various industry where crushing of dry and hardened elements is required, and when there are stones to be disposed of, enabling rolling. In cases of very hard stones, the Disintegrator expels them from the line. It has a flat roller and one with knives that work in different rotations also making the prelamination of the clay. The passage between the rollers is from 4 to 12 mm depending on the model of the machine. Used in ceramic industries in general, recyclers and others.
| Image | Model | Production | Power | Dimensions (WxHxL) | Approximate weight | Smooth Cylinder Dimensions (ØxW) | Dimensions of Lam. Cylinders Rechargeable (ØxW) |
|---|---|---|---|---|---|---|---|
![]() | MN-600C PREMIUM | Ut to 30 Ton/hour | 10 hp - 1150 rpm + 20 hp - 1750 rpm | 1370 x 2590 x 2445 mm | 2800 kg | Ø600 x 550 mm | Ø420 x 550 mm |
